How to Replace Taillight and Bulb 2000-05 Mercury Sable
Created on: 2012-01-03
Learn how to replace the tail light and bulb yourself with the steps in this how-to video
-
step 1 :Removing the Taillight
- Remove the thumb screw.
- Pull the trim panel up and push the insulation forward.
- Remove the four 11mm nuts on the back of the taillight.
- Disconnect the harness.
- Push the plug out.
- Pull the taillight out and off.
-
step 2 :Changing a Bulb
- Twist the socket out counterclockwise.
- Pull the bulb out.
- Push a new bulb in.
- Twist the socket clockwise to lock.
-
step 3 :Replacing the Taillight
- Twist out the sockets and remove the harness from the old taillight.
- Twist the sockets into the new taillight.
- Push the harness and plug into place.
- Line up the taillight and push it into place.
- Connect the harness.
- Replace the four 11mm nuts.
- Put the insulation and trim panel back into place.
- Replace the thumb screw.
While 1A Auto strives to make the information provided in this video as accurate as possible, it makes no claims, promises, or guarantees about the accuracy, completeness or applicability of the content. No information contained in this video shall create any expressed or implied warranty or guarantee of any particular result. All do-it-yourself projects entail some risk. It is the sole responsibility of the viewer to assume this risk. 1A Auto is not responsible or liable for any loss damage (including, but not limited to, actual, consequential, or punitive), liability, claim, or any other injury or cause related to or resulting from any information posted in this video.
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
In this video we're going to show you how to service the taillights on this 2002 Mercury Sable, same as a 2000-2003. Only tool you'll need is an 11 millimeter wrench.
To service a taillight, and you can see actually this one's cracked and a lot of states won't even let something like that go, but you want to come back here and most likely you're going to find a little thumb screw here. Mine's actually missing but you want to remove that and then you can take this piece here actually and pull it up, pry and pull up, and then you'll find four bolts back here: one, two there and then there's another two right over there.
What I found is once you loosen these up a couple of turns you should be able to just use your fingers and pull them off the rest of the way.
I'm just speeding it up here. As you can see, like I said, they come off in a few turns by the wrench and then you can usually get them off by your fingers. Make sure you remove all four. Once you've gotten those all out, right down here is your connector. You'll pull out on a little tab and then pull it up and out and then up here just force this little rubber plug through. Pull your light out, pull the connector out, if you're just going to change bulbs, twist counterclockwise, pull out the bulbs, pull from the socket, push back in, clockwise will lock, same with this one here.
New light from 1A Auto, seats all going to be the same. You do need to change your harness over, so you just turn those counterclockwise. Pull this little clip out, pull up from there, pull the clip off of the new one, install that on there, put the clip back on. Make sure the little rubber gaskets are on your connectors and you're ready to install. Obviously, it installs the same way. Put your connection through. You push your plug into place, push your light into place and bring your connector over, plug it back in, and then start your nuts on.
I'm going to fast forward through this. You put all the nuts on by hand first and then when you tighten them you don't want to tighten them incredibly tight. Once you feel that they're seated, probably only like a half of a turn more. You could break the light if you tighten them up too much. Push this all back in and flip your panel back on and put the thumb screw back in here if you have it, and there's our new taillight installed.
We hope this helps you out brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll free 888-844-3393. We're the company that's here for you on the Internet and in person.
