How to Replace Ignition Coil 2010-16 GMC Terrain
Created on: 2014-02-07
How to remove, install, repair, or replace your broken misfiring or damaged ignition coil on GMC Terrain, years 10, 11, 12, 13, and 14.
-
step 1 :Accessing the Ignition Coils
- Disconnect the small hose from the air intake box
- Use a flat blade screwdriver to loosen the upper and lower hose clamps
- Remove the oil fill cap
- Pull the engine cover up and off
- Put the oil fill cap back on
-
step 2 :Removing the Ignition Coil
- Push back the white clip on the ignition coil wiring harness
- Disconnect the harness
- Remove the 10mm bolt from the coil
- Pull the ignition coil out by hand
-
step 3 :Installing the New Ignition Coil
- Push the new ignition coil in by hand
- Insert the 10mm bolt
- Reconnect the wiring harness
- Push the white clip on the harness in
- Repeat Steps 2 and 3 for the other coils as necessary
-
step 4 :Reinstalling the Engine Cover
- Remove the oil fill cap
- Put on the engine cover, lining up the three pins
- Push on the air intake box using the two tabs
- Push the hoses into the air intake box
- Tighten the hose clamps with a flat blade screwdriver
- Push the smaller hose into the air intake box
Tools needed
-
Ratchet
Flat Blade Screwdriver
10mm Socket
While 1A Auto strives to make the information provided in this video as accurate as possible, it makes no claims, promises, or guarantees about the accuracy, completeness or applicability of the content. No information contained in this video shall create any expressed or implied warranty or guarantee of any particular result. All do-it-yourself projects entail some risk. It is the sole responsibility of the viewer to assume this risk. 1A Auto is not responsible or liable for any loss damage (including, but not limited to, actual, consequential, or punitive), liability, claim, or any other injury or cause related to or resulting from any information posted in this video.
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the ignition coil on this 2014 GMC Terrain with a 2.4-liter four-cylinder engine. The only tool that you're going to need for this is a flat-blade screwdriver and a 10mm socket and ratchet.
Start off by disconnecting this hose. Then you want to loosen up this clamp. There's another one right down here. As you can see, you just need a flat-blade screwdriver and loosen up that bolt. Once both of those are loosened, pull the hoses free, and then lift that box up and off. Now, remove your oil-fill cap and pull up the engine cover. Replace the oil cap so nothing falls down into the engine.
Right here are your ignition coils. Push back on the white clip. Then, push the tab on the harness and pull it free. Then, using a 10mm socket and ratchet remove the 10mm bolt. Then, the ignition coil will pull up and out. Take your new ignition coil and push it down into place. Then replace that 10mm bolt. Repeat the process for any of the other coils you might want to replace.
Reconnect your harness and push that clip back in. Remove your oil cap. Line up these three holes with these three pins. Push your engine cover down into place. You want to line up those two holes with those two tabs and you want to push your upper hose into place. Then push that lower hose into place. We'll fast-forward as Don tightens up those two hose clamps. Then, push in that smaller hose and you're all set.
We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
