How to Replace Air Temperature Control 2000-13 Chevy Silverado 1500
Created on: 2011-06-23
Watch this video to learn how to fix heating and cooling problems. The experts at 1A Auto show you how to replace the A/C and heater air temperature control on your 99-06 Chevy Silverado or Suburban, or GMC Sierra.
-
step 1 :Removing the Air Temperature Door Actuator
- Remove the four 7mm bolts from beneath the glove box
- Remove the trim
- Remove the two 7/32 bolts from the door actuator
- Disconnect the wiring harness
-
step 2 :Installing the Air Temperature Door Actuator
- Make sure the key is off
- Insert the actuator into place
- Tighten the two 7/32 bolts to the actuator
- Connect the wiring harness
- Insert the trim into place
- Tighten the four 7mm bolts to the trim
Tools needed
-
Socket Extensions
7mm Socket
Ratchet
7/32 Inch Socket
While 1A Auto strives to make the information provided in this video as accurate as possible, it makes no claims, promises, or guarantees about the accuracy, completeness or applicability of the content. No information contained in this video shall create any expressed or implied warranty or guarantee of any particular result. All do-it-yourself projects entail some risk. It is the sole responsibility of the viewer to assume this risk. 1A Auto is not responsible or liable for any loss damage (including, but not limited to, actual, consequential, or punitive), liability, claim, or any other injury or cause related to or resulting from any information posted in this video.
Brought to you by 1aauto.com. Your source for quality replacement parts and the best service on the internet.
In this video, we're going to be replacing the temperature door actuator on this '02 GMC Sierra. This is usually the problem when you turn your temperature control knob, and you don't get any warmer or cold air. You're either just getting warm or just cold or just one temperature. Tools you'll need are a 7mm socket and a 7/32s inch socket with an extension and a ratchet.
On the passenger side, there are four 7mm bolts to remove: one there and one in there. There's one up in that hole right there. I can't really film it. And then over here, closer to the gas pedal there is one right there. Once you remove those bolts, just reach in, kind of pull it down and out of the way.
The actuator is right down here. It's held in with two bolts, they're 7/32s. One of them is right over here. The other one's on the opposite side. It’s a little more difficult to get to. Kind of have to stuff the wrench in there. Kind of starts coming out, and you can disconnect your wrench and just use the socket. Okay.
So the actuator then comes down and out, and there's a little connector right here. Just push and disconnect. Very important when replacing one of these actuators. Make sure that you do not power the actuator up before it's installed.
So make sure your key is off, and you'll see that I actually install it before I plug it in. So install. Push it up and in, and get on the pin in there. I'm starting this bolt over here. Just use my socket. Okay and the final part is to put your cover back in place. You want to push it up in there.
You push it kind of against the firewall first. And I'm sorry about shaking around a little bit here, just trying to film with one hand and push it up in there with the other. Push the front of it up and in first and then make sure you have everything lined up. Okay.
As you could see here, these are the passenger side outlet holes. Make sure those are all lined up and then start your end bolt here, and then I'd recommend starting the ones over near the driver side. Once you have those lined up, then the other two middle ones go in pretty easily.
We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the internet.
Please feel free to call us toll free 888-844-3393. We're the company that's here for you on the internet and in person.
